Angle of View
H: 87° (110.8°/55°)
Audio Interface
1ch in & Built-in Mic
BLC Mode
BLC HLC WDR
Certifications
CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014 UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Close Focus Distance
2500mm – 98.43”
Day/Night
Auto (ICR) Manual
Effective Pixels
3840(H)×2160(V), 8MP
Electronic Shutter Speed
NTSC: 1/3s~1/100,000s PAL: 1/4s~1/100,000s
Focal Length
3.6mm
Focus Control
N/A
Frame Rate
15fps@4K, 20fps@6MP, 25/30fps@4MP
Gain Control
AGC
Image Sensor
1/2″ CMOS
IR Distance
Up to 40m (130feet)
IR LEDs
2
IR On/Off Control
Auto Manual
Lens Type
Fixed lens / Fixed iris
Max Aperture
F1.6
Minimum Illumination
0.005Lux/F1.6, 30IRE, 0Lux IR on
Mount Type
Board-in
Net Weight
0.42kg (0.93lb)
Noise Reduction
2D 3D
OSD Menu
Multi-language
Resolution
8MP (3840×2160)
S/N Ratio
More than 65dB
Scanning System
Progressive
Video Output
1-channel BNC high definition CVBS (DIP switch)
WDR
120dB
ابعاد
179.9mm×70mm×70mm (7.08″×2.76″×2.76″)
پوشش
آلومینیم
رنگ
سفید
سازنده
داهوا
شرایط عملیاتی
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH / Start up should be done at above -30°C (-22°F)
شرایط نگهداری
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
شیب
0° ~ 90°
کفه
0° ~ 360°
محافظت از دخالت و خرابکاری
IP67
مدل
DH-HAC-HFW2802EP-A
مصرف برق
Max 6.8W (12V DC, IR on)
منبع تغذیه
12V DC ±30%
وزن
0.53 kg
